Kontron microETXexpress-PV User’s Guide
34
Pin
Signal
Description
Type
Terminati
on
Comment
D88
PEG_TX11+
PCIe Graphics
Transmit+ (11)
Not
connected
nc
nc
D89
PEG_TX11-
PCIe Graphics
Transmit- (11)
Not
connected
nc
nc
D90
GND (Fixed)
Power Ground
PWR
-
-
D91
PEG_TX12+
PCIe Graphics
Transmit+ (12)
Not
connected
nc
nc
D92
PEG_TX12-
PCIe Graphics
Transmit- (12)
Not
connected
nc
nc
D93
GND
Power Ground
PWR
-
-
D94
PEG_TX13+
PCIe Graphics
Transmit+ (13)
Not
connected
nc
nc
D95
PEG_TX13-
PCIe Graphics
Transmit- (13)
Not
connected
nc
nc
D96
GND
Power Ground
PWR
-
-
D97
PEG_ENABLE#
PEG Enable
Not
connected
nc
nc
D98
PEG_TX14+
PCIe Graphics
Transmit+ (14)
Not
connected
nc
nc
D99
PEG_TX14-
PCIe Graphics
Transmit- (14)
Not
connected
nc
nc
D100
GND (Fixed)
Power Ground
PWR
-
-
D101
PEG_TX15+
PCIe Graphics
Transmit+ (15)
Not
connected
nc
nc
D102
PEG_TX15-
PCIe Graphics
Transmit- (15)
Not
connected
nc
nc
D103
GND
Power Ground
PWR
-
-
D104
VCC_12V
12V VCC
PWR
-
-
D105
VCC_12V
12V VCC
PWR
-
-
D106
VCC_12V
12V VCC
PWR
-
-
D107
VCC_12V
12V VCC
PWR
-
-
D108
VCC_12V
12V VCC
PWR
-
-
D109
VCC_12V
12V VCC
PWR
-
-
D110
GND (Fixed)
Power Ground
PWR
-
-
NOTE: The termination resistors in this table are already mounted on the
ETXexpress® board. Refer to the PICMG COM Express® Design Guide for
information about additional termination resistors.
