Pin
Signal
Description
Type
Terminati
on
Comment
D62
PEG_TX3-
PCIe Graphics
Transmit- (3)
Not
connected
nc
nc
D63
RSVD
Reserved
Not
connected
nc
nc
D64
RSVD
Reserved
Not
connected
nc
nc
D65
PEG_TX4+
PCIe Graphics
Transmit+ (4)
Not
connected
nc
nc
D66
PEG_TX4-
PCIe Graphics
Transmit- (4)
Not
connected
nc
nc
D67
GND
Power Ground
PWR
-
-
D68
PEG_TX5+
PCIe Graphics
Transmit+ (5)
Not
connected
nc
nc
D69
PEG_TX5-
PCIe Graphics
Transmit- (5)
Not
connected
nc
nc
D70
GND (Fixed)
Power Ground
PWR
-
-
D71
PEG_TX6+
PCIe Graphics
Transmit+ (6)
Not
connected
nc
nc
D72
PEG_TX6-
PCIe Graphics
Transmit- (6)
Not
connected
nc
nc
D73
SDVO_CLK
SDVO Clock
Not
connected
nc
nc
D74
PEG_TX7+
PCIe Graphics
Transmit+ (7)
Not
connected
nc
nc
D75
PEG_TX7-
PCIe Graphics
Transmit- (7)
Not
connected
nc
nc
D76
GND
Power Ground
PWR
-
-
D77
IDE_CBLID
IDE Cable Type
Identification
I – 3.3
PD of 10K Not 5V tolerant
per the COM.0
spec. Connected
to ICH8M pin
GPIO38.
D78
PEG_TX8+
PCIe Graphics
Transmit+ (8)
Not
connected
nc
nc
D79
PEG_TX8-
PCIe Graphics
Transmit- (8)
Not
connected
nc
nc
D80
GND (Fixed)
Power Ground
PWR
-
-
D81
PEG_TX9+
PCIe Graphics
Transmit+ (9)
Not
connected
nc
nc
D82
PEG_TX9-
PCIe Graphics
Transmit- (9)
Not
connected
nc
nc
D83
RSVD
Reserved
Not
connected
nc
nc
D84
GND
Power Ground
PWR
-
-
D85
PEG_TX10+
PCIe Graphics
Transmit+ (10)
Not
connected
nc
nc
D86
PEG_TX10-
PCIe Graphics
Transmit- (10)
Not
connected
nc
nc
D87
GND
Power Ground
PWR
-
-
