Kontron COMe-cPV2(v1.4) User Manual
Page 58
Kontron microETXexpress-PV User’s Guide
54
»
Mates with: (Molex) 51021-0400
»
Crimp terminals: (Molex) 50079-80000 (26-28 AWG)
6.3.1
Fan Connector Electrical Characteristics
The fan connector has two supply pins. One of the supply pins outputs a
regulated +5V with a maximum current of 350mA. The second supply pin is
connected directly from the VCC_12V supply from the COM Express connector
.The maximum current supported on that output is 125mA @ 60°C ambient because
it is current limited by a resettable fuse. The voltage is not limited to
+12V on this pin.
WARNING
: Be aware of the wide range input voltage and acceptable fan voltage
when connecting a fan to ht VCC_12V (Pin 2) output.
