A0h JILI-EEPROM No EEPROM for
JILI Data 4
7.5 System Management Bus (SMBus)
Table 27: SMBus Address Assignments
Address Device Notes JIDA Bus
Nr .
12h SMART_CHARGER Not to be used with any SMBus device
except a charger
1
14h SMART_SELECTOR Not to be used with any SMBus device
except a selector
1
16h SMART_BATTERY Not to be used with any SMBus device
except a battery
1
5Ch ON Semiconductor ADT7476
HWM
Do not use under any circumstances 1
A0h SPD EEPROM on DDR2 Do not use under any circumstances 1
A2h SPD EEPROM on DDR2 Do not use under any circumstances 1
D2h Clock Gen
CK610/ICS9DB403
Do not use under any circumstances 1
7.6 K-Station / JIDA32 Resources
Table 28: I
2
C
Bus Function
I2C 0 Internal / JIDA I2C #1
I2C 1 SMBus
I2C 2 Internal / JIDA I2C #2 (for
slow devices)
I2C 3 JILI I2C
Table 29: Storage
Device Function
EEPROM 0 JIDA EEPROM Area 1 with 32 Bytes (free
to use)
Table 30: GPIO
Port Function
IO-Port 0 GPIO Port, Bit 0-3: Input, Bit 4-7:
