Kontron microETXexpress-PV User’s Guide
21
Pin Signal Description Type Terminati
on
Comment
A10
9 VCC_12V 12V VCC
PWR
- -
A11
0 GND (Fixed) Power Ground
PWR
- -
Table 6: Connector X1A - Row B
Pin Signal Description Type Terminati
on
Comment
B1 GND (Fixed) Power Ground PWR - -
B2 GBE0_ACT# Ethernet Activity
LED O-
3.3/3.3SUS - -
B3 LPC_FRAME# LPC Frame
Indicator
O-3.3
- -
B4 LPC_AD0 LPC Address /
Data Bus
I/O-3.3
- -
B5 LPC_AD1 LPC Address /
Data Bus
I/O-3.3
- -
B6 LPC_AD2 LPC Address /
Data Bus
I/O-3.3
- -
B7 LPC_AD3 LPC Address /
Data Bus
I/O-3.3
- -
B8 LPC_DRQ0# LPC DMA request
I-3.3
PU 3.3 of
-20K in
the ICH8M -
B9 LPC_DRQ1# LPC DMA request
I-3.3
PU 3.3 of
-20K in
the ICH8M -
B10 LPC_CLK LPC Clock O-3.3 - -
B11 GND (Fixed) Power Ground PWR - -
B12 PWRBTN# Power Button
Input
I – 3.3 SUS
Weak
pullup in
the CPLD -
B13 SMB_CLK SMBus Clock
I/O-3.3 SUS
PU 3.3
SUS of
2.2K -
B14 SMB_DAT SMBus Data
I/O-3.3 SUS
PU 3.3
SUS of
2.2K -
B15 SMB_ALERT# SMBus Interrupt
I/O-3.3 SUS
PU 3.3
SUS of
10K -
B16 SATA1_TX+ SATA 1 Transmit
Data+
DP-O
- -
B17 SATA1_TX- SATA 1 Transmit
Data-
- -
B18 SUS_STAT# Indicates
imminent suspend
O-3.3 SUS
- -
