Kontron COMe-cPV2(v1.4) User Manual
Page 32
Kontron microETXexpress-PV User’s Guide
28
Pin
Signal
Description
Type
Terminati
on
Comment
Receive+ (0)
connected
C53
PEG_RX0-
PCIe Graphics
Receive- (0)
Not
connected
nc
nc
C54
TYPE0#
Not connected for
Type 2 module
Not
connected
nc
nc
C55
PEG_RX1+
PCIe Graphics
Receive+ (1)
Not
connected
nc
nc
C56
PEG_RX1-
PCIe Graphics
Receive- (1)
Not
connected
nc
nc
C57
TYPE1#
Not connected for
Type 2 module
Not
connected
nc
nc
C58
PEG_RX2+
PCIe Graphics
Receive+ (2)
Not
connected
nc
nc
C59
PEG_RX2-
PCIe Graphics
Receive- (2)
Not
connected
nc
nc
C60
GND (Fixed)
Power Ground
PWR
-
-
C61
PEG_RX3+
PCIe Graphics
Receive+ (3)
Not
connected
nc
nc
C62
PEG_RX3-
PCIe Graphics
Receive- (3)
Not
connected
nc
nc
C63
RSVD
Reserved
Not
connected
nc
nc
C64
RSVD
Reserved
Not
connected
nc
nc
C65
PEG_RX4+
PCIe Graphics
Receive+ (4)
Not
connected
nc
nc
C66
PEG_RX4-
PCIe Graphics
Receive- (4)
Not
connected
nc
nc
C67
RSVD
Reserved
Not
connected
nc
nc
C68
PEG_RX5+
PCIe Graphics
Receive+ (5)
Not
connected
nc
nc
C69
PEG_RX5-
PCIe Graphics
Receive- (5)
Not
connected
nc
nc
C70
GND (Fixed)
Power Ground
PWR
-
-
C71
PEG_RX6+
PCIe Graphics
Receive+ (6)
Not
connected
nc
nc
C72
PEG_RX6-
PCIe Graphics
Receive- (6)
Not
connected
nc
nc
C73
SDVO_DATA
SDVO Controller
Data
Not
connected
nc
nc
C74
PEG_RX7+
PCIe Graphics
Receive+ (7)
Not
connected
nc
nc
C75
PEG_RX7-
PCIe Graphics
Receive- (7)
Not
connected
nc
nc
C76
GND (Fixed)
Power Ground
PWR
-
-
