Pin Signal Description Type Terminati
on
Comment
A39 USB4- USB Data- Port #4
DP-I/O
- Connected to
USB port #6 on
the ICH8M.
A40 USB4+ USB Data+ Port #4 -
A41 GND (Fixed) Power Ground PWR - -
A42 USB2- USB Data- Port
#2-
DP-I/O
- Connected to
USB port #2 on
the ICH8M.
A43 USB2+ USB Data+ Port
#2+ -
A44 USB_2_3_OC# USB Overcurrent
Pair 2/3
I-3.3/ 3.3
SUS
PU 3.3
SUS of
10K ohms Connected to
over current
pin 2/3 of
ICH8M.
A45 USB0- USB Data- Port
#0-
DP-I/O
- Connected to
USB port #6 on
the ICH8M.
A46 USB0+ USB Data+ Port
#0+ -
A47 VCC_RTC RTC Power Supply
+3V
PWR
- -
A48 EXCD0_PERST# PCIe Express Card
0 Reset
O-3.3
- Connected to
GPIO1 on the
ICH8M.
A49 EXCD0_CPPE# PCIe Express Card
0 Request
I-3.3
PU 3.3 of
10K ohms Connected to
GPIO8 on the
ICH8M.
A50 LPC_SERIRQ LPC Serial
Interrupt Request
IO-3.3
PU 3.3 of
8.2K ohms -
A51 GND (Fixed) Power Ground PWR - -
A52 PCIE_TX5+ PCIe 5 Transmit
Data+ Not
connected nc nc
A53 PCIE_TX5- PCIe 5 Transmit
Data- Not
connected nc nc
A54 GPI0 General Purpose
Input0
I-3.3
PU 3.3 of
10K ohms Connected to
CPLD
A55 PCIE_TX4+ PCIe 4 Transmit
Data+
DP-O
- -
A56 PCIE_TX4- PCIe 4 Transmit
Data-
- -
A57 GND(Fixed) Power Ground PWR - -
A58 PCIE_TX3+ PCIe 3 Transmit
Data+
DP-O
- -
A59 PCIE_TX3- PCIe 3 Transmit
Data-
- -
A60 GND (Fixed) Power Ground PWR - -
A61 PCIE_TX2+ PCIe 2 Transmit
Data+ DP-O
- -
A62 PCIE_TX2- PCIe 2 Transmit - -
