Kontron microETXexpress-PV User’s Guide
17
Pin Signal Description Type Terminati
on
Comment
A15 SUS_S3# Indicates Suspend
to RAM state
O-3.3 SUS
- -
A16 SATA0_TX+ SATA 0 Transmit
Data+
DP- O
- -
A17 SATA0_TX- SATA 0 Transmit
Data- - -
A18 SUS_S4# Indicates Suspend
to Disk state
O-3.3 SUS
- -
A19 SATA0_RX+ SATA 0 Receive
Data+
DP-I
- -
A20 SATA0_RX- SATA 0 Receive
Data- -
A21 GND (Fixed) Power Ground PWR -
A22 SATA2_TX+ SATA 2 Transmit
Data+
DP-O
- -
A23 SATA2_TX- SATA 2 Transmit
Data- - -
A24 SUS_S5# Indicates Soft
Off state
O-3.3 SUS
- -
A25 SATA2_RX+ SATA 2 Receive
Data+
DP-I
- -
A26 SATA2_RX- SATA 2 Receive
Data- - -
A27 BATLOW# Indicates low
external battery
I-3.3/3.3
SUS
PU 3.3V
SUS in
CPLD (5K
to 25K
ohms -
A28 (S)ATA_ACT# SATA Activity
Indicator
O-3.3
- -
A29 AC/HDA_SYNC HD Audio Sync O-3.3 - -
A30 AC/HDA_RST# HD Audio Reset O-3.3 - -
A31 GND(Fixed) Power Ground PWR - -
A32 AC/HDA_BITCLK HD Audio Clock O-3.3 - -
A33 AC/HDA_SDOUT HD Audio Data O-3.3 - -
A34 BIOS_DIS0# Disable Module
BIOS. Enables
boot from a BIOS
on Baseboard
I-3.3/3.3
SUS
PU 3.3V
SUS of
51.1K
ohms -
A35 THRMTRIP# CPU thermal
shutdown
indicator
O-3.3
- Pin state is
not valid in
Suspend Power
A36 USB6- USB Data- Port #6
DP-I/O
- Connected to
USB port #8 on
the ICH8M.
A37 USB6+ USB Data+ Port #6 -
A38 USB_6_7_OC# USB Over current
Pair 6/7
I-3.3/ 3.3
SUS
PU 3.3V
SUS of
10K ohms Connected to
over current
pin 8/9 of
ICH8M.
