Kontron microETXexpress-PV User’s Guide

Specifications

3.1

Functional Specification

Processor: Intel® Atom™ Technology

CPU:

Intel® Atom™ N450 single core, 5.5W TDP
Intel® Atom™ D410 single core, 10.5W TDP
Intel® Atom™ D510 dual core, 15W TDP
All with integrated DRAM and graphics

Cores:

Up to 2 cores

Bus Speed:

Up to 2 x 1.66 GHz

Cache:

L1 cache 24KB write-back data/32KB instruction
L2 cache up to 2x512 KB, 8-way

Memory:

Up to 2GB (single channel) DDR2 S0DIMM (667 MHz only)

2x 1GB configuration only

Video Controller:

Integrated, Intel® GMA 3150 (200 MHz for N450 or 400

MHz for D410/D510) with DirectX*9-compliant Pixel Shader
2.0
Intel® Clear Video Technology:
MPEG2 Hardware Acceleration
ProcAmp
Intel® Dynamic Video Memory Technology 4.0

Graphics:

Analog VGA, with max resolution 1400x1050 at 60 Hz for the
N450 or 2048x1536 at 60 Hz for the D410/D510.
18-bit single channel LVDS with resolution 1366x768

Features:

Hyper-Threading Technology (HTT)

Execute Disable Bit

BIOS-enabled enhanced Intel® SpeedStep Technology (modules

with the N450 CPU only)

CPU Sleep States:

D510/D410: C0/C1

N450: C0/C1(E)/C2(E)/C4(E)

Instruction Set:

IA 32-bit and Intel® 64 architecture

Package:

22mm x 22mm

Thermal Spec:

Operation: 0° to 70°C
Storage: -10° to 85°

Chipset: Intel® I/O Controller Hub 82801HBM (ICH8M)

USB:

8xUSB 2.0

Audio:

Intel® High Definition Audio (24 bit / 96 kHz) controller
