Kontron COMe-cPV2(v1.4) User Manual
Page 51
Kontron microETXexpress-PV User’s Guide
47
WARNING: The following signal is not 5V tolerant as required by the COM
Express 2.0 specification:
- Pin D48 - PCI_CLKRUN#
IDE Port
The IDE host adapter on the Intel® ICH8M supports PATA/UDMA-33/66/100
operation. The implementation of this subsystem complies with the COM
Express® Specification. For additional implementation information, refer to
the PICMG COM Express® Design Guide on the PICMG website.
WARNING: The following signal is not 5V tolerant as required by the COM
Express 2.0 specification:
- Pin D77 - IDE_CBLID
