1 si6-10b2, 1 specifications, 2 connector – Kontron VM162 User Manual
Page 86: Appendix si6 piggybacks, 1 specifications 1.2 connector
Appendix SI6 Piggybacks
Page SI6- 2
© PEP Modular Computers
Juli 23, 1997
1
SI6-10B2
The SI6-10B2 is a physical Cheapernet (10Base2) interface to the 68EN360 Controller chip. It connects one of the range
of PEP CPU boards to a 50
Ω
coax cable via an RG58 BNC ‘T’ connector.
The SI6-10B2 has two LEDs fitted; a red LED indicates collision detection and a yellow LED for data.
1.1 Specifications
1.2 Connector
On-board termination
Max. Baud Rate
None (Cheapernet cable is terminated at both ends)
10 Mbit/s as specified by Ethernet
