3.2.5 CXC Mode
The enhanced CXC describes the multiplexing of the CXC address lines in order to enhance the address
range to 16MByte. This is used today in conjunction with the CXM-PFB12 PROFIBUS board. Please
consult the relevant CXM User’s Manual to set the CXC mode.
Jumper
Setting
Description
J11
Set
Enhanced CXC mode enabled
Open
Enhanced CXC mode disabled
Default
