VM162/VM172 Chapter 1 Introduction
Juli 23, 1997 Page 1- 9 © PEP Modular Computers
a. With 4 Mbyte DRAM, 256 kByte SRAM and 1 MByte FLASH memory.
VMEbus Interface
DIN 41612 (C), 96-pin P1/P2 connector
A32/A24/A16:D32/D16/D8 master
A24:D16 slave
Networking
All Ethernet interfaces conform to IEEE 802-3 and
are available on SI6-xx piggybacks
SC-Interface
Serial Interface from MC68EN360 (ports SCC2,
SCC3 and SCC4) with standard RS232 configuration
Power Consumption
a
VM162 w/ MC68060
≈
6.5W @ 50 MHz
VM172 w/ MC68040
≈
8.5W @ 33 MHz
Temperature
0ºC to +70ºC (standard)
-40ºC to +85ºC (extended / storage)
Humidity 0 to 95% non-condensing
Weight/Dimensions
440 g (with 10BaseT and memory piggybacks)
233mm x 160mm 6U format
Front Panel Functions
3 LEDs: red : Halt
yellow : Watchdog enabled
green
: General purpose user
