VM162/VM172 Chapter 2 Functional Description
Juli 23, 1997 Page 2- 25 © PEP Modular Computers
CXC
Function
Pin Nr.
68302 HW
Compatible 68(EN)360
Port
Comment
IRQ_1 a1 Yes PC0
IRQ_2 a2 Yes PC1
IRQ_3 a3 Yes PC2
IRQ_4 a4 Yes PC3
CXC
Function
Pin Nr.
68302 HW
Compatible 68(EN)360
Port
Comment
DMA_ACK c2 Yes PB5
DMA_REQ c3 Yes PB4
CXC
Function
Pin Nr.
68302 HW
Compatible 68(EN)360
Port
Comment
SER1_RCLK b1 Yes PA8
SER1_TCLK b2 Yes PA10
SER1_TXD b4 Yes PA3
SER1_RXD b10 Yes PA2
SER1_RTS b5 Yes PB13
SER1_DTR a13 Yes PB17
SER1_CTS b13 Yes PC6
SER1_CD b14 Yes PC7
