VM162/VM172
Chapter 3 Configuration
Page 3- 8
© PEP Modular Computers
Juli 23, 1997
3.3.1 CPU Type
3.3.2 CPU Power Supply
3.3.3 CPU (Bus) Clock
3.3.4 SRAM Size
Jumper
Setting
Description
J3
Set
CPU type is 68060
Open
CPU type is 68040 or 68040V
Jumper
Setting
Description
J12 - J15
1-2
CPU power is 5 volt (68040)
1-3
CPU power is 3.3 volt (68040V or 68060)
Jumper
Setting
Description
J5
J6
J5 - J7
Set
Set
CPU Bus clock is 25.0 MHz
Open
Set
CPU Bus clock is 33.3 MHz
Jumper
Setting
Description
J19
J20
J19 - J20
1-2
1-2
SRAM size is 1 MByte
1-3
1-3
SRAM size is 256 kByte
