VM162/VM172

Chapter 3 Configuration

Page 3- 4

© PEP Modular Computers

Juli 23, 1997

3.2 Jumper Description (Component Side)

Figure 3.1 VM162/VM172 Jumper Layout (Component Side)

VME

Connector

VME

Connector

VME

Connector

P

2

RJ45/Mini-D-Sub

Serial port

Connector

s

RJ45,

RJ58

or

15-Pin

D-Sub

Connector

VME

Connector

P

1

J8
Protective GND
Signal GND

J1 VME Boot

J2 ROM Boot

VME SYSRES * J10

J11 CXC Mode
