Page 45
VM162/VM172
Chapter 2 Functional Description
Juli 23, 1997
Page 2- 23
© PEP Modular Computers
2.8.3 TERM Pinout
The port based on the SMC is fixed to RS232 interfaces. This port supply RxD/TxD interfaces with soft-
ware handshake (XON/XOFF) capability. Usually, this port is used as terminal/debug port.
RJ45 Connector
Mini D-Sub Female Connector
N/C: Not Connected
Pin
Signal
1
N/C
2
N/C
3
GND
4
TxD
5
RxD
6
N/C
7
N/C
8
DTR
Pin
Signal
1
N/C
2
RxD
3
TxD
4
N/C
5
GND
6
N/C
7
N/C
8
N/C
9
N/C
