VM162/VM172 Chapter 2 Functional Description
Juli 23, 1997 Page 2- 33 © PEP Modular Computers
2.10.10 IP Interrupt Control Register
IP Interrupt Control Register Bit-map:
Address: IPa: NEX CE 00 09 01
IPa: NEX CE 00 0B 01
Format: byte
Access: read and write
Value after Reset: HEX 00
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
INT1_EN INT1_IL2 INT1_IL1 INT1_IL0 INT0_EN INT0_IL2 INT0_IL1 INT0_IL0
INT1_EN 0 -> IP interrupt request on INT1 line disabled
1 -> IP interrupt request on INT1 line enabled
INT1_IL2-0 IP IRQ level for INT1 line (1 or 3 or 5 or 7)
INT0_EN 0 -> IP interrupt request on INT0 line disabled
1 -> IP interrupt request on INT0 line enabled
INT0_IL2-0 IP IRQ level for INT0 line (2 or 4 or 6)
