Series 8700 / 8800 Unitized Cutain Wall Assembly Instructions - Volume 1
Table of Contents
Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1
EFCO 2011 Page 4
Note: Assembly Instructions are provided as a supplement, and should be used in conjunction with
the approved shop drawings.
Volume 5 of 6
30. Hardware Mounting On Unit Assembly
31. Hardware Mounting On Sash
32. Mounting Vent Assembly Into Unit Assembly
Volume 6 of 6
33. Shadow Box Assembly
34. Shadow Box Installation
35. Shadow Box Insulation Installation
36. Back Panel Installation
37. Back Panel Insulation Installation
38. Final Cleaning
Minimizing Condensation
Note: Please reference EFCO's "Understanding Condensation" brochure which can be obtained through your EFCO
representative.
Condensation will form on any surface when unfavorable conditions (interior temperature and relative humidity
and exterior temperature) are present. When the formation of excessive condensation is a concern, it is highly
recommended that a design professional is utilized to perform an analysis of the shop drawings to recommend the
best possible installation methods. Please contact your EFCO representative for information on EFCO's Thermal
Analysis Services.
Many current installation practices lead to an increase in the possibility of the formation of condensation.
Though not all inclusive, the list of examples below illustrates conditions under which condensation is likely to occur:
1. Bridging system thermal break with non-thermally broken metal flashing or lintels that are exposed to
the exterior
2. System exposure to cold air cavities
3. Interior relative humidity levels not maintained at recommended levels, see EFCO’s “Understanding
Condensation” brochure
4. Inadequate separation between system and surrounding condition at perimeter
5. Product combinations during the shop drawing stage that result in bridging thermal breaks
of one or all products involved
