Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1

15. Tool the sealant into the joint between the “Z” clip and the mullion.
16. Remove excess sealant if required.

Figure 15

Figure 14

Tool the

sealant into the

joints

Section 3 - Unit Frame Assembly : A. Mullion Subassembly
