Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1

Section 2 - Parts Identification : E. Extrusions - 8" System

Profile

Part #

Description

Tooling/Cut Length Formula

Extrusions - 8" System

17H8

8" CAPTURED AND SSG DYNAMIC
STARTER SILL

U17H8-001, U17H8-002, U17H8-003,
U17H8-004, U17H8-005

17H7

8" DYNAMIC STARTER SILL GUTTER
BASE

U17H7-001, U17H7-002, U17H7-003,
U17H7-004, U17H7-005

8" STACK SILL MULLION ANCHOR BAR REFERENCE FM04 PART DRAWING

17J3

FABRICATED #

FM04

Frame Extrusions - 8" System Vent Frames

17K2

CONCEALED VENT HEAD AND SILL
HORIZONTAL

U17K2-001

1H65

CONCEALED VENT HORIZONTAL
STACK SILL

U1H65-001, U 1H65-002
