Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1
Section 2 - Parts Identification : H. Concealed Vent Extrusions
Profile
Part #
Description
Tooling/Cut Length Formula
Concealed Vent Extrusions
1H66
SSG AND CAPTURED VERTICAL SASH
CAPTURED HEAD SASH
U1H66-001, U1H66-002, U1H66-003
1H68
CAPTURED SILL SASH
U1H68-001
1H70
CAPTURED SILL SASH AT STACK SILL
UH170-001
1H67
SSG HEAD AND SILL SASH
U1H67-001, U1H67-002
1H69
SSG SILL SASH AT STACK
U1H69-001
