Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1

Section 2 - Parts Identification : B. Frame Extrusions - 7" System

Profile

Part #

Description

Tooling/Cut Length Formula

Frame Extrusions - 7" System

17A0

7" CAPTURED AND SSG VERTICAL
MULLION

U17A0-001, U17A0-002, U17A0-003,
U17A0-004, U17A0-005, U17A0-006,
U17A0-007, U17A0-008

17A1

7" CAPTURED AND SSG VERTICAL
MULLION

U17A1-001, U17A1-002, U17A1-003,
U17A1-004, U17A1-005, U17A1-006,
U17A1-007, U17A1-008

17G4

7" OPTIONAL CAPTURED AND SSG
VERTICAL MULLION

U17G4-001, U17G4-002, U17G4-003,
U17G4-004, U17G4-005, U17G4-006,
U17G4-007

17G5

7" OPTIONAL CAPTURED AND SSG
VERTICAL MULLION

U17G5-001, U17G5-002, U17G5-003,
U17G5-004, U17G5-005, U17G5-006,
U17G5-007, U17G5-008

17B2

7" CAPTURED AND SSG HORIZONTAL
STACK HEAD

CUT TO LENGTH (D.L.O.) AT
TYPICAL FLAT UNITS

17C1

7" CAPTURED AND SSG
INTERMEDIATE HORIZONTAL

CUT TO LENGTH (D.L.O.) AT
TYPICAL FLAT UNITS
