EFCO 2009

Page 19

Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1

Section 2 - Parts Identification : G. Extrusions

Profile

Part #

Description

Tooling/Cut Length Formula

Extrusions

17B1

CAPTURED HORIZONTAL STACK
GUTTER

U17B1-001, U17B1-002, U17B1-003,
U17B1-004

17B6

SSG HORIZONTAL STACK GUTTER

U17B6-001, U17B6-002, U17B6-003,
U17B6-004

17D1

FABRICATED #

FM11

MULLION ANCHOR

REFERENCE FM11 PART DRAWING

17D2

FABRICATED #

FM05 & FM06

FM05 - HOOK ANCHOR (LEFT)

FM06 - HOOK ANCHOR (RIGHT

REFERENCE FM05 AND FM06 PART
DRAWING

12D8

FABRICATED #

FM17

BOLT RETAINER

REFERENCE FM17 PART DRAWING

8806

FABRICATED #

FM18

CAPTURED AND SSG JAMB SPACER

REFERENCE FM18 PART DRAWING
