EFCO 2009

Page 14

Series 8700 / 8800 Unitized Curtain Wall Assembly Instructions - Volume 1

Section 2 - Parts Identification : C. Extrusions - 7" System

Profile

Part #

Description

Tooling/Cut Length Formula

Frame Extrusions - 7" System

17C3

7" CAPTURED AND SSG DYNAMIC
STARTER SILL

U17C3-001, U17C3-002, U17C3-003,
U17C3-004, U17C3-005

17C5

7" DYNAMIC STARTER SILL GUTTER
BASE

U17C5-001, U17C5-002, U17C5-003,
U17C5-004, U17C5-005

7" STACK SILL MULLION ANCHOR BAR REFERENCE FM03 PART DRAWING

17D6

FABRICATED #

FM03

FM13 - 7" VERTICAL MULLION SPLICE
BAR (RIGHT)
FM14 - 7" VERTICAL MULLION SPLICE
BAR (LEFT)

REFERENCE FM13 AND FM14 PART
DRAWING

17A7

FABRICATED #

FM13 & FM14
