EFCO 5500X Outside Glazed User Manual
Page 57
EFCO 2012
Page 57
Series 5500 XTherm
™
Curtain Wall Assembly and Installation Instructions
Section 14 - Vertical Splice Joints
Section 14 - Vertical Splice Joints
1”
minimum
3”
minimum
Use backer rod and
sealant to form a
ramp to guide water
Install backer rod as
required to seal splice
joint and pressure plate
