Series 5500 xtherm – EFCO 5500X Outside Glazed User Manual
Page 19
EFCO 2012
Page 19
Series 5500 XTherm
™
Curtain Wall Assembly and Installation Instructions
Section 8 - Shop Applied Joint Plugs
Figure 7
TYPICAL SINGLE SPAN FRAMES
Typical Left Jamb Frame
(See Figure 8, Page 20)
Typical Intermediate
Frame
(See Figure 9, Page 21)
Typical Expansion
Mullion Frames
(See Figure 10, Page 22)
Expansion
Mullions
Typical Right Jamb Frame
(See Figure 11, Page 23)
