EFCO 5500X Outside Glazed - Manual (Page 5)

EFCO 2012 Page 5
Series 5500 XTherm ™ Curtain Wall Assembly and Installation Instructions
Profile
WEP8 Standard 1/4” Preset Glazing Gasket Peroxide Cure 60 Duro Shore A EPDM
Part # Description Material
Accessories
Profile Part # Description Profile Part #
Section 2 - Parts Identification - Fasteners and Accessories
#13-16 X 5/8" HWH-SMS 18-8 A GM SFQ5 1/4"-14 X 1 1/2" HWH SHOULDER- SMS 18-8 B
Fasteners
STC0
Description
WT01 Standard Isolator Gasket
Shore A 90 Duro General
Purpose Flexible PVC
WEP4 Standard 1/4” Preset Perimeter Spacer Gasket Peroxide Cure 70 Duro Shore A EPDM
WEP0 Standard 1/4” Preset SSG Spacer Gasket General Purpose 70 Duro Shore A Silicone
SFZ8 #8-15 X 1/2" PL-FH-SMS 18-8
STK4 #8-18 X 1/2" PL-FH-SMS 410 TEK/2
#8-18 X 9/16" PL-FH-SMS ZC TEK/2 STT6
