EFCO 5500X Outside Glazed - Manual (Page 44)

EFCO 2012 Page 44
Series 5500 XTherm ™ Curtain Wall Assembly and Installation Instructions
Section 12 - Install Twin Span Frame Components
12. Refer to the final approved shop drawings for the size, configuration, and other information for anchors welded to steel structure conditions.
Figure 52
Jamb Section
Figure 53
Jamb Section
Attach the filler and mullion
sections together with
fasteners as noted in the final
approved shop drawings.
9/32”
9/32”
Drill (4) 1/8” pilot holes in the filler and main
section of the vertical. Attach the filler and
mullion section together with fasteners as
noted in the final approved shop drawings.
Wind Load
Anchor
Perimeter
O.G. Mullion
Floor Slab
Jamb
Condition
Wind Load
Anchor
Floor Slab
