AVer SEB5116 series - Manual (Page 53)

47
3.2.2 Motion and Mask Setting
Click Default will back to the factory default value.
i
In Select Cameras, SEB5108H series only has 8 channels will be available.
(1)
(2)
(3)
(4)
(1) Select Camera
Select the camera number you want to configure. To select all cameras, mark Select All check box.
(2) Motion Mask
Enable/disable the motion detection and motion mask setup.
- Enable: Enable/disable motion detection.
- Sensitivity: Set the sensitivity level of motion detector. The higher the value, the finer the
sensitivity is detected.
- Motion Mask: Mark an area on the screen to disregards the motion detects in the marked
area and to only detects motion outside the marked area. Use the mouse drag from up to
down to select a motion mask area. To un-select the mask area, drag from down to up. Also,
user can click block one by one to select and un-select the mask area.
(3) Video Shield
Video shield covers an area on the screen and the covered area would not be visible on the screen
and recorded.
- Video Shield Enable: Enable/disable video shield function.
- Video Shield: To select an area for video shield. Use the mouse drag from up to down to
select a video cover area. To un-select the cover area, drag from down to up. Also, user can
click block one by one to select and un-select the cover area.
(4) Video Mask
Mark an area on the screen to disregards the monitor in the marked area and to only monitor
outside the marked area.
- Video Mask Enable: Enable/disable video shield function.
- Video Mask: To select an area for video mask. Use the mouse drag from up to down to
