AVer SEB5116 series - Manual (Page 31)

25
2.3.1.1 Familiarizing the Buttons in PTZ Control Panel
(6) (5) (4) (3) (2)
(1)
(10)
(9)
(8) (7)
Name Function
(1) Close Exit PTZ camera controller.
(2) Setup Configure PTZ cameras.
(3) Auto Pan Operate the PTZ cameras automatically based on the selected camera group
preset position number.
(4) Focus +/- Adjust the focus manually to produce clear image.
(5) Zoom +/- Zoom in and out the image.
(6) Direction buttons Adjust and position the focal point of the PTZ camera.
(7) Camera lens
speed controller
Adjust the moving speed of the PTZ camera lens.
(8) Camera preset
position number
Move the PTZ camera to the preset point.
(9) Save Camera
preset position
Save the PTZ camera preset position number. Select the camera and click the
preset position number and save it.
(10) Group Auto Pan Select to automatically operate PTZ camera in group.
