2
Finding Information
What are you looking for? Find it here
• Drivers for my printer Software and Documentation disc
• My User's Guide
The Software and Documentation disc contains setup video, documentation,
and drivers for your printer. You can use the Software and Documentation disc to
install drivers or access your setup video and documentation.
Readme files may be included on your Software and Documentation disc to
provide last-minute updates about technical changes to your printer or advanced
technical reference material for experienced users or technicians.
• How to use my printer Quick Reference Guide
Dell ™ C2660dn Color Laser Printer
Quick Reference Guide
Front and Rear View About the Operator Panel
1 14 The operator panel has a 4-line LCD panel, a status LED, control buttons, and a number pad, which
allows you to control the printer.
15 12 13 1
11 2 16
10 2 3 9
23 3
4 4 4 10 22 17 21 3 9
8 5 20 5 18 8
7 6
19 6
1 Transfer Belt Unit 13 Top Cover
2 Drum Cartridges 14 Ethernet Port
3 Waste Toner Box 15 Wireless Adapter Socket 7
4 Right Side Cover 16 USB Port
5 Power Switch 17 Left Side Cover 1 Status LED (Ready / Error) Shows a green light when the printer is ready and a blinking green light
6 Tray1 18 Control Board when data is being received.
7 Optional 550-Sheet Feeder (Tray2) 19 Duplex Unit Shows an amber light when an error occurs and a blinking amber light
when an unrecoverable print error occurs. 8 Multipurpose Feeder (MPF) 20 2nd Belt Transfer Roller (2nd BTR)
Displays various settings, instructions, and error messages. 9 Toner Cartridges 21 Fusing Unit 2 LCD Panel
10 Front Cover 22 Power Connector 3 button Moves the cursor or highlight up or down.
11 Operator Panel 23 Rear Cover 4 button Moves the cursor or highlight right or left.
12 Output Tray Extension 5 (Cancel) button Cancels active or pending jobs.
6 Number Pad Enters numbers and characters. Service Tag Express Service Code xxxxxxx 000 000 000 00 7 (Power Saver) button Enters or exits the Power Saver mode. When the machine is not used for a while, it enters the Power Saver mode to reduce power consumption.
When the Power Saver mode is active, the Power Saver button blinks.
Service Tag
8 (Back) button Returns to the previous screen.
9 (Menu) button Moves to the top level of the menu.
10 (Set) button Confirms the entry of values.
NOTE: Moving to a different menu or returning to a previous screen cancels the current entry or setting. Make sure to
October 2013 press the (Set) button to save the current entry or setting.
NOTE:
Quick Reference Guide
may not be included in the package for some
regions.
Finding Information 21
