Dell C2660dn Color Laser Printer - Manual (Page 139)

Magenta Toner Cartridge Displays the magenta toner level.
Yellow Toner Cartridge Displays the yellow toner level.
Black Toner Cartridge Displays the black toner level.
*1 The menu title is displayed only when Wi-Fi Direct is set to Enable.
*2 This item is displayed only when Wi-Fi Direct is set to Enable.
Google Cloud Print
Purpose:
To register the printer to Google Cloud Print.
Values:
Google Cloud Print *1 (Registration state) Displays the Google Cloud Print registration state.
Register This Device to Click to register the printer to Google Cloud Print.
Google Cloud Print
*1 Google Cloud Print can only be used when the machine is using IPv4.
Proxy Server
Purpose:
To configure the Proxy Server settings.
Values:
Proxy Server Use Proxy Server Sets whether to enable the use of a proxy server.
Address to Bypass Proxy Sets the address to bypass proxy server.
Server
Server Name
Sets the name of the proxy server.
Port Number Sets the port number from 1 to 65535.
Authentication Sets whether to enable authentication.
Login Name Sets the login name for the proxy server.
Password Sets the login password for the proxy server.
Retype Password Confirms the set password.
Dell™ Printer Configuration Web Tool 137
