16 About the System
Figure 1-3. Back-Panel Features and Indicators — Server Enclosure with External
Power Source
6 Service mode
button
Press this button within 4 seconds to enter
service mode.
7 External PDU
connector
Connects to a PDU control connector.
8 BMC management
port
Dedicated management port.
9 Chassis
identification
indicator
Lights blue when the chassis ID signal is
generated.
10 Power/event
indicator
Indicates the power and health status of the
enclosure.
Item Feature Icon Description
1
2 3 4 5 6 7 8 9 10
