Using the System Setup Program 135
4845 PCIe Slot ASPM Controls the level of ASPM supported on the given
PCI Express Link of port. L0s entry downstream and
L1 enabled
4846 Onboard LAN
ASPM
Controls the level of ASPM supported to onboard
LAN. All entry disabled.
4847 Onboard LAN
ASPM
Controls the level of ASPM supported to onboard
LAN. L0s entry enabled.
4848 Onboard LAN
ASPM
Controls the level of ASPM supported to onboard
LAN. L1 entry enabled.
4849 Onboard LAN
ASPM
Controls the level of ASPM supported to onboard
LAN. L0s and L1 entry enabled.
484A Onboard LAN
ASPM
Controls the level of ASPM supported to onboard
LAN. L0s entry downstream enabled.
484B Onboard LAN
ASPM
Controls the level of ASPM supported to onboard
LAN. L0s entry downstream and L1 enabled.
484C Mezzanine Slot
ASPM
Controls the level of ASPM supported on Mezzanine
Slot. All entry disabled.
484D Mezzanine Slot
ASPM
Controls the level of ASPM supported on Mezzanine
Slot. L0s entry enabled.
484E Mezzanine Slot
ASPM
Controls the level of ASPM supported on Mezzanine
Slot. L1 entry enabled.
484F Mezzanine Slot
ASPM
Controls the level of ASPM supported on Mezzanine
Slot. L0s and L1 entry enabled.
4850 Mezzanine Slot
ASPM
Controls the level of ASPM supported on Mezzanine
Slot. L0s entry downstream enabled.
4851 Mezzanine Slot
ASPM
Controls the level of ASPM supported on Mezzanine
Slot. L0s entry downstream and L1 enabled.
4852 NB-SB Link
ASPM
Controls the level of ASPM supported on the NB-SB.
All entry disabled.
4853 NB-SB Link
ASPM
Controls the level of ASPM supported on the NB-SB.
L1 entry enabled.
Table 2-1. D4 Token Table (continued)
Token Setup Option Description
