ENGINEER DATE
JOB NAME SIZE MACHINE SERIAL NO.
TIME OF DATA
HOUR METER READING
HOT OR
CHILLED
WATER
Heating or Cooling
Temperature Entering
Temperature Leaving
Pressure Entering
Pressure Leaving
COOLING
WATER
Temperature Entering Absorber
Temperature Leaving Absorber
Temperature Leaving Condenser
Pressure Entering Absorber
Pressure Leaving Absorber
Pressure Leaving Condenser
BURNER
Selected Fuel
Fuel Supply Pressure
Fuel Valve Position
Air Damper Position
Exhaust Gas Temperature
Exhaust O
2
or CO
2
REFRIG-
ERANT
Pump Discharge Temperature
Specific Gravity
High-Stage Vapor Condensing Temperature
Low-Stage Vapor Condensing Temperature
Refrigerant Overflow?
WEAK
SOLUTION
Actual Temperature
Sample Temperature
Specific Gravity
Concentration
Saturation Temperature
Alcohol in Sample?
Temperature Leaving Low-Temperature
Heat Exchanger
Temperature Leaving High-Temperature
Heat Exchanger
STRONG
SOLUTION
Temperature Leaving High-Stage Generator
Temperature Leaving Low-Stage Generator
Temperature To Sprays
Fig. 33 — Typical 16DF Maintenance Record Log Sheet
