4.6 OPTION FUNCTIONS
The OPTIONS MODE is accessed by means of
the [MODE] key. Use the [5] or [6] key to scroll
through the menu of options shown opposite.
The first three functions are described earlier in
Section 2.4.2-2.4.4 of this manual. The CARTRIDGE
TYPE function may be needed in connection with
service problems. Before requesting technical
assistance on any problem relating to the analyzer,
obtain the identification number of the installed
software cartridge by accessing the CARTRIDGE
TYPE function; then press the [NEXT] key and
record the software version number.
Note: The software number is also displayed during
the start-up routine and appears on the software
cartridge label.
See Section 2.5.1 for a description of the SET
BAUD RATE option.
To exit any option function, press [MODE] to
advance the display to the primary CBC MODE.
4.7 QBC CAPILLARY CENTRIFUGE
QBC hematology tests require the centrifugation of
blood samples at the specified RCF for 5 minutes
to obtain proper cell banding. The QBC Capillary
Centrifuge is designed to fulfill this requirement.
When using the QBC Capillary Centrifuge, be sure
to place tubes on the centrifuge rotor in a balanced
array (see example in Figure 4-8).
Detailed operating instructions and calibration
check procedures are described in the QBC
Capillary Centrifuge operator’s manual.
4-10
MESSAGES
PRESS [5] KEY
MESSAGES
PRESS [5] KEY
MESSAGES
PRESS [5] KEY
MESSAGES
PRESS [5] KEY
MESSAGES
PRESS [5] KEY
MESSAGES
MESSAGES
OPTIONS MODE
Select... [5] [6]
Autoread Plus
Set Date & Time
Autoread Plus
Set Language
Autoread Plus
Set Print Format
Autoread Plus
Set Units
Autoread Plus
Cartridge Type
Autoread Plus
Set Baud Rate
*
* IN APPLICABLE SOFTWARE
Figure 4-8.
QBC Tubes with Balance Tube in Even (#4) Position
