92
NTA607HD or NTA2007HD
Great Plains Manufacturing, Inc.
166-370M
05/25/2011
174
802-910C
RHSNB 3/4-10 X 2 GR5 PLT
Removed. Not re-used.
175
803-006C
NUT HEX 1/4-20 PLT
Removed. Some re-installed.
176
803-014C
NUT HEX 3/8-16 PLT
Removed. Not re-used.
177
803-020C
NUT HEX 1/2-13 PLT
Removed. Some re-installed.
178
803-021C
NUT HEX 5/8-11 PLT
Removed. Re-installed.
179
803-027C
NUT HEX 3/4-10 PLT
Removed. Some re-installed.
180
803-049C
NUT HEX 7/8-9 PLT
Removed. Re-installed.
181
803-147C
NUT HEX NYLOCK 1/2-13
Removed. Some re-installed.
182
803-342C
NUT HEX TOP LOCK 1/2-13 PLT
Removed. Re-installed.
183
804-006C
WASHER LOCK SPRING 1/4 PLT
Removed. Some re-installed.
184
804-009C
WASHER LOCK SPRING 5/16 PLT
Removed. Re-installed.
185
804-011C
WASHER FLAT 3/8 USS PLT
Removed. Not re-used.
186
804-013C
WASHER LOCK SPRING 3/8 PLT
Removed. Not re-used.
187
804-015C
WASHER LOCK SPRING 1/2 PLT
Removed. Some re-installed.
188
804-017C
WASHER FLAT 1/2 USS PLT
Removed. Re-installed.
189
804-022C
WASHER LOCK SPRING 5/8 PLT
Removed. Re-installed.
190
804-023C
WASHER LOCK SPRING 3/4 PLT
Removed. Some re-installed.
191
804-029C
WASHER FLAT 1 SAE
Removed. Re-installed.
192
804-037C
WASHER LOCK SPRING 7/8 PLT
Removed. Re-installed.
193
804-039C
WASHER FLAT 1 1/4 SAE PLT
Removed. Re-installed.
194
804-117C
WASHER FLAT 1/4 HARD ASTMF436
Removed. Re-installed.
195
805-104C
PIN COTTER 3/16 X 1 1/2 PLT
Removed. Re-installed.
196
805-117C
PIN ROLL 1/4 X 2 1/2 PLT
Removed. Re-installed.
197
805-124C
PIN CLEVIS 1 X 3 11/16 GR5 PLT
Removed. Re-installed.
198
805-155C
PIN WIRE RETAIN 5/16 X 2 1/2
Removed. Re-installed.
199
805-187C
PIN CLEVIS 1 X 2 1/4 GR5 PLT
Removed. Re-installed.
200
805-255C
PIN ROLL 3/8 X 2 1/2 PLT
Removed. Re-installed.
201
806-010C
U-BOLT 1/2-13 X 2 1/2 X 3 1/2
Removed. Some re-used.
202
806-105C
U-BOLT 5/8-11 X 4 1/32 X 6
Removed. Re-installed.
203
807-268C
SPRING COMP DIE.75X.375X1.50L
Removed. Not re-used.
204
808-192C
GEAR 17 TOOTH QUICK CHANGE
Removed. Re-installed.
205
810-170C
CYL REP 3.5X10X1.25 ROD (TIE)
Removed. Re-installed.
206
810-219C
CYL 3.5X16X2 ROD (TIE ROD)
Removed. Re-installed.
207
810-345C
VALVE 90 DEGREE SHUT-OFF
Removed. Not re-used.
208
810-442C
MW STOP BUSH SET 1 1/4 SBS125
Relocated.
209
811-080C
TE 3/4MJIC 3/4MORB 3/4MJIC
Two removed. One re-used.
210
811-150C
EL 3/4FJIC 3/4MJIC
Two removed. One re-used.
211
811-195C
HH1/2R1 028 3/4FJIC 3/4MORB
Disconnected and re-connected.
212
811-291C
HH1/2R2 072 3/4FJIC
Un-clamped and re-clamped.
213
811-324C
AD 3/4MORB 3/4FJIC
Removed. Not re-used.
214
811-512C
HH1/2R2 219 3/4FJIC 3/4MORB
Removed and re-connected.
215
811-617C
HH1/2R2 140 3/4FJIC
Un-clamped and re-clamped.
Call
out
Part
Number
Part Description
Part Disposition
