Appendix P - Part Lists
The part call-out numbers in this list match all Figures in
these installation instructions. Part descriptions match
those in your updated Parts Manual. Quantities are units (“ea”).
Existing Parts Affected
The following existing parts are involved in the kit instal-
lation. The Disposition column indicates whether the part is left
in place, moved or not re-used.
Call
out
Part
Number
Part Description Part Disposition
101 113-370D 1/4 MARKER HYD HOSE GUARD Removed. Re-installed.
102 136-223D CHAIN RL #40 138 PITCHES Dismounted. Re-mounted.
103 149-059D COULTER CLAMP BAR Loosened. Re-tightened.
104 160-201H WING PIVOT PIN WELDMENT Removed. Re-installed.
105 160-314H REAR PARALLEL LIFT LINK WELDMT Removed. Re-installed.
106 160-315H NTA607HD FRONT PULL LINK WLDMT Removed. Replaced by new weldment.
107 160-316H NTA607HD REAR PULL LINK WELDMT Removed. Not re-used.
108 160-317H NTA607HD LIFT ASST FRAME WLMT Removed. Re-installed.
109 160-321H BACK PRESSURE FLEX LINK WELDMT Left in place.
110 160-323H PIN WLDMNT 1.25 X 15.66 NR Removed. Re-installed.
111 160-324H PIN WLDMNT 1.25 X 12.34 NR Removed. Re-installed.
112 160-328H LIFT ASSIST LINK WELDMENT Removed. Re-installed.
113 160-329H LIFT LINK ADJUSTER TRUNNION Disconnected and re-connected.
114 160-331S NTA607HD HYDRAULIC VALVE ASY Relocated.
115 160-754D NTA607 PULL LINK CYLINDER LUG Removed. Re-installed.
116 160-760D TRANSPORT LOCK PIN 1 X 8.25 Removed. Re-installed.
117 160-763D NTA607HD PIN STORAGE BRACKET Removed. Re-installed.
118 160-781D PIN 1 1/2 X 4 USABLE 1045 Removed. Re-installed.
119 160-787D DOUBLE SHOOT TOWER MOUNT ANGLE Left in place.
120 160-788D DBL SHOOT BLOCKAGE MONITOR MNT Left in place or removed. Not re-used.
121 166-285H CART DRILL FRAME WLDMNT Modified.
122 166-289H 82/82 HOPPER MOUNT Removed w/hoppers. Re-installed.
123 166-297H EXTENDED TONGUE WELDMENT Modified.
124 166-300K 4-OUTLET METER ASSEMBLY Removed. Re-installed.
125 166-308/20/21S 4-OUTLET STAR SHAFT ASY Removed. Re-installed.
125 166-308S 4-OUTLET METER 2-STAR SHFT ASY Removed. Re-installed.
125 166-320S 4-OUTLET METER 3-STAR SHFT ASY Removed. Re-installed.
125 166-321S 4-OUTLET METER 4-STAR SHFT ASY Removed. Re-installed.
126 167-020H LID SWIVEL WELDMENT Left in place. Parts changed.
127 167-091H BIN LADDER Left in place.
128 167-283D BIN LID TOP CROSS BAR Removed. Updated. Re-installed.
129 168-125H 45T QUICK CHANGE SPKT WELDMENT Dismounted. Re-mounted.
130 168-243D GEAR 54 TOOTH QUICK CHANGE Removed. Re-installed.
131 168-409D METER SHAFT MOUNT PLATE Removed. Not re-used.
