SERVICING THE AT30
62
3.6. ORDERING REPLACEMENT PARTS
All AT30 Series battery chargers ship with a supplemental parts data
package, itemizing all components within the unit. Contact your sales
representative to place an order for spare or replacement parts. Please
provide the following information for each component:
•
Model number and serial number of your AT30 Series battery charger
•
Circuit symbol, factory part number and description from the supplied
Parts Data Package report
•
Quantity required
Note: Some of the factory part numbers listed on the Parts Data Package report may
differ from the standard replacement part numbers listed in this manual. Custom parts
may have replaced standard parts to satisfy your specification. In that case, you
should order the part number(s) listed on the report. The following table may specify
part replacement kits that include other materials, such as installation instructions and
packaging materials. You may order spare parts using either part number. To be sure
of getting the complete kit, specify "Complete Kit" on your order, and the factory will
make the necessary adjustments.
Refer to the table below for the most common items.
Table 3-1: REPLACEMENT PARTS
Factory Part Number
Symbol Description
12 Vdc 24 Vdc 48 Vdc 130 Vdc
Rec.
Spares
A1 Main Control PC Board assembly EJ1243-10 Y
A5 Auxiliary Relay PC Board assembly (optional) EJ1243-03 Y
A10 Temperature Compensation Probe assembly See Appendix B
A15 Three Phase Gate driver PC Board assembly EJ5199-01 EJ5199-02 EJ5199-03 EJ5199-04 Y
A16 SCR Rectifier Module(s) - (Q1-Q6) see supplied Parts Data Package Y
A17x SCR Snubber Sub-Assembly PC Board EN5012-00
C1 Filter Capacitor (standard) see supplied Parts Data Package Y
C2 Filter Capacitor (battery eliminator) see supplied Parts Data Package Y
C4 EMI Filter Capacitor see VR6/C4
C5 EMI Filter Capacitor see VR7/C5
CB1 AC Input Circuit Breaker see supplied Parts Data Package
CB2 DC Output Circuit Breaker see supplied Parts Data Package
CR1 Polarity Diode (25-50 Adc ratings) RK0013-14 Y
CR1 Polarity Diode (75 Adc rating) RK0014-14 Y
CR1 Polarity Diode (100-400 Adc ratings) RK0017-14 Y
CR1 Polarity Diode (500-600 Adc ratings) RK0028-12 Y
CR1 Polarity Diode (800-1K0 Adc ratings) PM0003-00 Y
CR4 Free-Wheeling Diode (25-50 Adc ratings) RK0013-14 Y
CR4 Free-Wheeling Diode (75 Adc rating) RK0014-14 Y
CR4 Free-Wheeling Diode (100-400 Adc ratings) RK0017-14 Y
CR4 Free-Wheeling Diode (500-600 Adc ratings) RK0028-12 Y
CR4 Free-Wheeling Diode (800-1K0 Adc ratings) PM0003-00 Y
F1A/B/C AC Input Fuses see supplied Parts Data Package Y
F3/F4 DC Output Fuses see supplied Parts Data Package Y
