SERVICING THE AT10.1
68
Table 3-18: HIGH AMPERE INTERRUPTING CAPACITY DC CIRCUIT BREAKERS (CB2)
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0043-07 RE0043-07 RE0043-07 RE0043-07
40 Adc
RE0043-08 RE0043-08 RE0043-08 RE0043-08
50 Adc
RE0043-10 RE0043-10 RE0043-10 RE0043-10
75 Adc
RE0043-12 RE0043-12 RE0043-12 RE0043-12
100 Adc
RE0188-06 RE0188-06 RE0188-06 n/a
Table 3-19: DC OUTPUT FUSES (F3/F4)
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0061-18 RE0061-18 RE0061-18 RE0061-18
40 Adc
RE0061-19 RE0061-19 RE0061-19 RE0061-19
50 Adc
RE0061-21 RE0061-21 RE0061-21 RE0061-21
75 Adc
RE0061-23 RE0061-23 RE0061-23 RE0061-23
100 Adc
RE0061-26 RE0061-26 RE0061-26 n/a
Table 3-20: MAIN INDUCTOR (L1)
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
AP0604-10 AP0604-10 AP0604-10 AP0604-10
40 Adc
AP0604-10 AP0604-10 AP0604-10 AP0482-10
50 Adc
AP0481-10 AP0481-10 AP0481-10 AP0482-10
75 Adc
AP0314-10 AP0808-10 AP0833-10 AP5001-00
100 Adc
AP0339-10 AP0339-10 AP0827-10 n/a
Table 3-21: FILTER INDUCTOR (L2)
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
AP0604-10 AP0604-10 AP0604-10 AP0604-10
40 Adc
AP0604-10 AP0604-10 AP0604-10 AP0604-10
50 Adc
AP0481-10 AP0481-10 AP0481-10 AP0482-10
75 Adc
AP0314-10 AP0314-10 AP0833-10 AP0377-10
100 Adc
AP0339-10 AP0339-10 AP0339-10 n/a
