SERVICING THE AT10.1
64
Table 3-2: DC FILTER ASSEMBLIES - STANDARD (L2/C1/R9/CR1)
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
EJ5031-00 EJ5031-05 EJ5031-10 EJ5031-15
40 Adc
EJ5031-01 EJ5031-06 EJ5031-11 EJ5031-16
50 Adc
EJ5031-02 EJ5031-07 EJ5031-12 EJ5031-17
75 Adc
EJ5031-03 EJ5031-08 EJ5031-13 EJ5031-18
100 Adc
EJ5031-04 EJ5031-09 EJ5031-14 n/a
Table 3-3: DC FILTER ASSEMBLIES - ELIMINATOR (C2) - REQUIRES STANDARD FILTER
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
EJ5031-20 EJ5031-25 EJ5031-30 EJ5031-35
40 Adc
EJ5031-21 EJ5031-26 EJ5031-31 EJ5031-36
50 Adc
EJ5031-22 EJ5031-27 EJ5031-32 EJ5031-37
75 Adc
EJ5031-23 EJ5031-28 EJ5031-33 EJ5031-38
100 Adc
EJ5031-24 EJ5031-29 EJ5031-34 n/a
Table 3-4: STANDARD AC CIRCUIT BREAKERS (CB1) - 120 Vac
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0015-04 RE0015-06 RE0015-09 RE0015-15
40 Adc
RE0015-05 RE0015-07 RE0015-10 RE0015-19
50 Adc
RE0015-05 RE0015-09 RE0015-12 RE0217-02
75 Adc
RE0015-07 RE0015-10 RE0015-15 RE0217-04
100 Adc
RE0015-09 RE0015-15 RE0015-19 n/a
Table 3-5: STANDARD AC CIRCUIT BREAKERS (CB1) - 208/240 Vac
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0015-04 RE0015-04 RE0015-06 RE0015-10
40 Adc
RE0015-04 RE0015-05 RE0015-07 RE0015-15
50 Adc
RE0015-04 RE0015-06 RE0015-09 RE0015-15
75 Adc
RE0015-05 RE0015-07 RE0015-12 RE0015-19
100 Adc
RE0015-06 RE0015-09 RE0015-15 n/a
