Exide Technologies Section 94.30 - Manual (Page 71)

SERVICING THE AT10.1
67
Table 3-14: AC INPUT FUSES (F1/F2) - 208/240 Vac
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0061-08 RE0061-09 RE0061-12 RE0061-16
40 Adc
RE0061-08 RE0061-11 RE0061-13 RE0061-21
50 Adc
RE0061-09 RE0061-12 RE0061-14 RE0061-21
75 Adc
RE0061-11 RE0061-13 RE0061-18 RE0061-23
100 Adc
RE0061-12 RE0061-15 RE0061-21 n/a
Table 3-15: AC INPUT FUSES (F1/F2) - 480 Vac
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0008-06 RE0008-06 RE0008-08 RE0008-12
40 Adc
RE0008-06 RE0008-08 RE0008-09 RE0008-13
50 Adc
RE0008-06 RE0008-08 RE0008-11 RE0008-14
75 Adc
RE0008-08 RE0008-09 RE0008-12 RE0008-18
100 Adc
RE0008-08 RE0008-11 RE0008-13 n/a
Table 3-16: STANDARD DC CIRCUIT BREAKERS (CB2)
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0015-30 RE0015-30 RE0015-30 RE0015-30
40 Adc
RE0015-31 RE0015-31 RE0015-31 RE0015-31
50 Adc
RE0015-34 RE0015-34 RE0015-34 RE0015-34
75 Adc
RE0015-36 RE0015-36 RE0015-36 RE0015-36
100 Adc
RE0217-03 RE0217-03 RE0217-03 n/a
Table 3-17: MEDIUM AMPERE INTERRUPTING CAPACITY DC CIRCUIT BREAKERS (CB2)
Current Rating 12 Vdc 24 Vdc 48 Vdc 130 Vdc
30 Adc
RE0170-07 RE0170-07 RE0170-07 RE0170-07
40 Adc
RE0170-08 RE0170-08 RE0170-08 RE0170-08
50 Adc
RE0170-10 RE0170-10 RE0170-10 RE0170-10
75 Adc
RE0170-12 RE0170-12 RE0170-12 RE0170-12
100 Adc
RE0217-03 RE0217-03 RE0217-03 n/a
