Exide Technologies Section 94.30 User Manual

Page 4

TABLE OF CONTENTS

QUICK OPERATION .................................................................................................. Back Cover
HOW TO READ THE AT10.1 MODEL NUMBER ..........................................Inside Front Cover
IMPORTANT SAFETY INSTRUCTIONS ......................................................................................i

1 Receiving and Installing the AT10.1 Battery Charger

1.1

Storing the AT10.1 .................................................................................................2

1.2

Reporting shipping damage ...................................................................................2

1.3

Unpacking and inspecting the AT10.1 ...................................................................2

Inspection checklist ................................................................................................2

1.4

Moving the AT10.1 .................................................................................................3

Enclosure type and weight table ............................................................................3

1.5

Mounting the AT10.1 ..............................................................................................3

1.5.1 Wall-Mounting the AT10.1 ...............................................................................4

1.5.2 Floor-Mounting the AT10.1 ..............................................................................6

1.5.3 Rack-Mounting the AT10.1 (optional) ..............................................................8

1.6

Changing transformer taps...................................................................................10

1.7

Making the ac input connections ..........................................................................12

1.8

Making the dc output connections........................................................................14

1.9

Wiring the AT10.1 for remote sensing..................................................................16

1.10 Wiring to the remote alarm contacts ....................................................................18

Auxiliary Relay Board (optional) ...........................................................................19

1.11 Installing the temperature compensation probe (optional) ...................................20

Using temperature compensation ........................................................................22

1.12 Installing the AT10.1 for remote communications (optional) ................................23

1.13 Installing the AT10.1 for forced load sharing (optional) .......................................23

2 Operating the AT10.1 Battery Charger

2.1

Starting the AT10.1

2.1.1 Understanding the start-up sequence............................................................24

2.1.2 Checking the installation ................................................................................24

2.1.3 Starting the AT10.1 ........................................................................................24

Using the digital meter ...................................................................................24

Factory settings table.....................................................................................25

2.2

Using the AT10.1 front panel features

2.2.1 If the meter displays an error message .........................................................26

2.2.2 Selecting the meter mode..............................................................................26

2.2.3 Selecting the Float or Equalize mode ............................................................27

2.2.4 Choosing the Equalize method......................................................................27

Manual Timer method....................................................................................27

Manual Equalize method ...............................................................................28

Auto-Equalize Timer method .........................................................................28

2.2.5 Testing the front panel indicators...................................................................29

2.2.6 Testing the Auxiliary Relay Board (optional) .................................................29

2.2.7 Interpreting the alarm indicators ....................................................................29
