nFORCE® LED Traffic Controller - Interior Use Only
ENFTCDGS12(xx)
nFORCE Traffic Controller 9.14
NORMAL OPERATION
Under Normal operation with ignition input powered, the breakout box will have the Green LED ON and the Red LED light will be ON whenever an input
is active and both switches are in the UP (off) position.
NO OPERATION
No Green LED on Breakout box;
Check input power and ground to lightbar and breakout box
Check Ignition Input wire and verify a minimum of 10.0 Volts is present on
the wire
NO or INCORRECT WARNING LIGHTs
No steady Red LED on breakout box;
Check 24-pin connector at breakout box (insure it is snapped in
correctly), check appropriate input to breakout box for output lights which
should be on. Verify voltage is present at the wire input to the breakout
box for the function being tested
NO TAKEDOWNS LIGHTS
Breakout box LED’s operating correctly;
Verify configuration and make sure light modules are configured for
takedown function
No steady Red LED on breakout box;
Check 24-pin connector at breakout box
(ensure it is snapped in
correctly), check appropriate input to breakout box for output lights which
should be on
INCORRECT OR NO ARROW OPERATION
Breakout box LED’s operating correctly;
Verify configuration and make sure light modules are configured for
arrow function
No steady Red LED on breakout box;
Check 24-pin connector at breakout box
(ensure it is snapped in
correctly), check appropriate input to breakout box for output lights which
should be on.
nForce TROUBLESHOOTING
10.
