7 How to ...?
VA Database 2.0
70
7.2 Data transfer 746 ---> VA Database
Send determinations to the database
1. If you want to observe the process of data transfer, click on
or MAIN WINDOW / Window / Communication to open the VA
COMMUNICATION window (the data transfer works also in the
background).
2. Load the determination to be sent into the working storage of
the 746 VA Trace Analyzer.
3. On dialog page "DOCUMENTATION" in the 746 VA Trace
Analyzer enter on a new line Report ActDetm in the COPY Re-
ports, Curves column and RSIfc.1 or RSIfc.2 in the TO destina-
tion column.
4. Activate the data transfer by moving the cursor to the de-
scribed line and pressing the softkey .
Using this procedure both the binary determination file ( *.dtm )
and the ASCII determination report file ( *.rpt ) are transferred and
stored in the database.
Note: If a method contains the line COPY Report ActDetm TO
RSIfc.# on the dialog page "DOCUMENTATION", the determina-
tion is sent automatically to the database after termination of the
analysis.
Each time a determination is sent to the database, determination
files ( *.dtm ) and ASCII determination report files ( *.rpt ) will be
stored automatically to the backup directory if the option
Save
original files is enabled in the SERIAL INTERFACE SETTINGS win-
dow (see Default directories, page 51).
Send determinations to the backup directory
1. If you want to observe the process of data transfer, click on
or
MAIN WINDOW / Window / Communication
to open the
VA
COMMUNICATION window (the data transfer works also in the
background).
2. Select the determination(s) to be sent on the dialog page
"DETERMINATIONS" or "DATA CARD" in the 746 VA Trace
Analyzer.
3. Press the softkeys and / .
The binary determination files ( *.dtm ) will be transferred to the
predefined backup directory (see Default directories, page 51).
