7 How to ...?
VA Database 2.0
83
curves (or select the corresponding item in the context sensi-
tive menu). The curve subwindow containing all substance,
calibration, or segment curves is opened in the
MAIN WIN-
DOW
.
Display curves from VA Explorer
1. Click on or MAIN WINDOW / Window / Explorer . The VA DA-
TABASE EXPLORER window will be opened or (if it is already
open) put on top.
2. Expand the database explorer tree until you see the curve
items.
3. Select the curve item whose curve should be displayed.
4. Click on
VA DATABASE EXPLORER / Determination / View or se-
lect View in the context sensitive menu or drag and drop the
view item directly to an empty space of the MAIN WINDOW .
The curve subwindow is opened in the MAIN WINDOW .
Whether it contains a single curve or all curves depends on
the view item selected (details see View reports and curves
from VA Explorer, page 44).
Display overlay curves
1. Click on or MAIN WINDOW / Window / Explorer . The VA DA-
TABASE EXPLORER window will be opened or (if it is already
open) put on top.
2. Expand the database explorer tree until you see the desired
curve items.
3. Select the curve item whose curve should be displayed.
4. Click on
VA DATABASE EXPLORER / Determination / View or se-
lect View in the context sensitive menu or drag and drop the
view item directly to an empty space of the MAIN WINDOW .
The curve subwindow is opened in the MAIN WINDOW .
Whether it contains a single curve or all curves depends on
the view item selected (details see View reports and curves
from VA Explorer, page 44).
5. Select another curve item of the same type (substance, cali-
bration, or segment) as the curve displayed.
6. Drag and drop the view item directly to the open curve sub-
window in the MAIN WINDOW . The related curves will be
added to the existing curve set. The axes are automatically
expanded to show all the curves completely.
7. Repeat steps 5...6 until all desired curves are displayed in the
curve subwindow.
