DJI Phantom 2 Vision User Manual - Manual (Page 70)

©2014 DJI. All Rights Reserved. 70 |
Specifications
Aircraft
Supported Battery DJI 5200mAh Li-Po Battery
PHANTOM 2 VISION Weight 1160g
Recommend payload ≤1300g
Maximum payload 1350g
Hovering Accuracy (Ready to Fly) Vertical: 0.8m; Horizontal: 2.5m
Max Yaw Angular Velocity 200°/s
Max Tilt Angle 35°
Max Ascent / Descent Speed Ascent: 6m/s; Descent: 2m/s
Max Flight Speed 15m/s (Not Recommended)
Wheelbase 350mm
Tilt Range of the Camera 0 ° - 60°
Remote Control
Operating Frequency 5.728 GHz －5.85 GHz
Communication Distance (open area) CE Compliance: 300m; FCC Compliance: 500m
Receiver Sensitivity (1%PER) -93dBm
Transmitting Power (EIRP) CE Compliance: 25mW; FCC Compliance: 125mW
Working Current/Voltage 80mA@6V
Battery 4 AA Batteries
Camera
Resolution 14 Megapixels
FOV 120 °/ 110° / 85°
Sensor Size 1/2.3”
Functions
Supports multi-capture, continuous capture and timed capture
Supports HD Recording (1080p30,1080i60)
Supports both RAW and JPEG photo formats
Range Extender
Operating Frequency 2412MHz - 2462MHz
Communication Distance (open area) 300m
Transmitting Power 17dBm
Power Consumption 1.5W
DJI VISION App
Supported Mobile Devices
Recommended: iPhone4s, iPhone5, iPhone5s, iPhone5C, iPod
Touch4, iPod Touch5;
Available but not recommended: iPad3, iPad4, iPad mini.
