©2014 DJI. All Rights Reserved. 15 |
(1)
(2)
(3)
(4)
(5)
Make sure to charge the range extender completely before using it for the first time.
If the power indicator is a solid red light, the ranger extender may stop working at any moment.
Recharge it as soon as possible.
It is recommended to charge the range extender completely before each use.
Turn off the range extender after every use.
Keep the range extender facing the aircraft during flight for the best communication link.
[3] Lock-screw
For attaching the range extender on the right side of the remote control’s carrying handle.
[4] Reset Button:
Press to link the range extender and the camera.
[5] Power Switch:
ON – Power on.
OFF – Power off.
[6] Micro-USB
Used to charge the range extender.
[7] Mounting Bracket
It has been pre-installed on the remote control’s handle. It is used to attach the range extender.
4.3 Powering on the Range Extender
1.
2.
Toggle the power switch of range extender to ON position.
Wait for approximately 30 seconds. The Wi-Fi signal indicator should blink green indicating the range
extender is communicating properly.
It is advised that you power off the range extender after every flight to avoid discharging the battery.
4.4 How to Bind the Camera & Range Extender
If the camera and range extender connection is lost, or one of them needs to be repaired or replaced, a camera and
range extender binding will need to be performed via the DJI VISION App.
