57 |

[5]

Battery Level

Battery level display. Refer to the

in Camera Page for details

[6]

GPS

Number of satellites connected. Refer to the

in Camera Page for details

[7]

Flight Attitude and Radar

Attitude and Radar display. Refer to the

in Camera Page for details

[8]

Flight Parameters

Flight information display. Refer to the

in Camera Page for details

[9]

Back

Return to camera GUI.

[10] Home Point Locator

Locate your Home point.

[11]

Orientation Lock

Unlock to sync map orientation with aircraft movement

[12] Map View

Select map view from standard, hybrid or satellite.

[13] Waypoint

Tap each waypoint to set altitude

[14] Delete

Delete current waypoint.

[15] Go Home

Abort mission, return home and land

[16] Done

Hit “Done” then tap “GO” to begin mission.

[17] Flight Area

The aircraft can fly in this area and return to the home point with the current battery level. This area is

dependent on the current state of the aircraft and will be refreshed at specific time intervals.
